Memory Application IC – Power Management IC (DDR5 PMIC)

VIN_Bulk input supply range: 4.25V to 5.5V Three step down switching regulators (6A/6A/2A) Programmable dual phase and single phase regulator for SWA and SWB 2 LDO regulators: VOUT_1.8V, VOUT_1.0V Programmable output voltages, power up and power down sequence for switch regulators Output switch regulators protection features: OVP, UVP, OCP Output current and power measurement Temperature measurement, warning threshold, critical temperature shutdown Multi Time Programmable (MTP) Non-Volatile Memory Programmable and DIMM specific registers for customization Flexible Open Drain IO (I2C) and Push Pull (I3C Basic) IO support Idle Power State (P1 State)

VIN_Bulk input supply range: 4.25V to 5.5V Three step down switching regulators (6A/6A/2A) Programmable dual phase and single phase regulator for SWA and SWB 2 LDO regulators: VOUT_1.8V, VOUT_1.0V Programmable output voltages, power up and power down sequence for switch regulators Output switch regulators protection features: OVP, UVP, OCP Output current and power measurement Temperature measurement, warning threshold, critical temperature shutdown Multi Time Programmable (MTP) Non-Volatile Memory Programmable and DIMM specific registers for customization Flexible Open Drain IO (I2C) and Push Pull (I3C Basic) IO support Idle Power State (P1 State)

Memory Application IC – Mixed Signal IC (SPD HUB、TS)

Two wire I2C or I3C Basic bus serial interface Up to 12.5 MHz transfer rate 1.8 V, 1.0 V power supply input 1.0 V Push Pull I/O levels 1.0 V, 1.1 V, 1.2 V, 1.8 V, 2.5 V, and 3.3 V Open Drain IO levels 1024 Bytes of non-volatile memory (16 blocks; 64 bytes per block) Hub Function Integrated Temperature Sensor Up to 8 unique addressing In Band Interrupt (IBI)

Micro Display Backplane Driver Related IPs and Products

pixel circuit: 7T3C~5T2C GOA: sequential driving/sync driving Mux: 1:2/1:3/1:6 ESD: 2KV/300V

Display ActiveArea: 1.2~1.4inch Resolution: 4k~5K pixel pitch: 5~6.3um PPI: 4032~5000ppi Refresh rate: 1Hz~120Hz Gray level: 10-bit Vdd: 8V
